Digital Wheel Balancer Functions
A brief list of the specific functions for Digital Wheel Balancer.
The 2 versions of Software, BASIC and FULL allow to satisfy different customer needs.
The BASIC version, which includes all the basic functions necessary for a wheel balancer measurement, is equipped on the B2xx and B32x range.
The FULL version, which adds all the advanced features to the BASIC version , is equipped on the B33x, B43x, B44x range.
BASIC (default) | FULL (Full option) | |
---|---|---|
Unit of measure mm / inches (user setup) | ![]() | ![]() |
START-STOP * Automatic when closing the Wheel guard (user setup) * optional for B212 | ![]() | ![]() |
Display step 1 or 5 gr (user setup) | ![]() | ![]() |
Display cut-off 1 to 9 gr (user setup) | ![]() | ![]() |
STOP-ON-TOP at the end of measuring run, wheel is stopped with point of application of weight placed at 12 o'clock | ![]() | ![]() |
Autodiagnostic a great number of malfunctions or user mistakes in procedure are detected | ![]() | ![]() |
Autocalibration sensor calibration can be easily performed by the user | ![]() | ![]() |
SPLIT Possibility to divide the balance weight and hide behind the spokes in a non-visible position | ![]() | ![]() |
Statistics | ![]() | ![]() |
FCC Fast Calibration Check | ![]() | ![]() |
ALU-S allows to measure and enter the exact position of adhesive weights to be placed on alloy rims | ![]() | ![]() |
MARS Automatic Minimization of Residual Static Unbalance allows to reduce the static unbalance left, due to rounding when using weights multiple of 5 grams. | ![]() | ![]() |
Optimization Tire matching Static (tire rotated on the rim) Dynamic (tire rotated/overturned on the rim) | ![]() | ![]() |
AFC Automatic Flange Calibration allows to use even non-balanced flanges (dirty, worn, etc.) | ![]() | ![]() |
ASF ALU Special Functions Allows to place adhesive weights at 6 o'clock and other useful functions. | ![]() | ![]() |
APS * Automatic Positioning System Allows to move wheel automatically to inside/outside position for application of the balancing weight. * APS is available only for model with Laser | ![]() | ![]() |
FAST Fast balancing mode Allows to measure wheel unbalance in half time (for when you have peak-hours time/periods). | ![]() | ![]() |
Double operator | ![]() | ![]() |
AUTOSELECT | ![]() | ![]() |
![]() ![]() |
